Nock Cortex CB496 Gyros Machine

The Nock Cortex CB 496 Gyros Machine is expertly designed for cutting high-quality slices of meat ideal for Doner and Gyros skewers. With a generous cutting width of 430mm and a cutting speed of 24 m/min, this machine features a unique blade holder, transport roller, and spring-suspended pressure roller.

These components work in harmony to ensure a superior cut and careful handling of meat, surpassing traditional derinders. The blade gap is adjustable from 0.5 to 8 mm, allowing for precise customisation, even during operation.

SKU: NOCK-CB496-GYROS Categories: , ,

Description

The Nock Cortex CB 496 is versatile and suitable for various meats, including veal, bull beef, pork, turkey breast, and lamb. It comes with the NOCK Integrated Product Return System, providing enhanced efficiency and safety. Key features include a spring-suspended blade holder and pressure roller, a tooth roller with a scraper comb, and an easily removable infeed conveyor. It also prioritises safety with access protection at the rear and boasts robust NOCK Power Plates® for durability and ease of maintenance. The machine is made of stainless steel, including stainless steel bearings, and has lockable castors for ease of mobility.

  • Cutting width: 430mm
  • Cutting speed: 24 m/min
  • Cutting direction: horizontally
  • Max. throughput height: 90mm
  • Blade gap: 0 – 8 mm, infinitely adjustable
  • Apply length on infeed conveyor: 400mm
  • Infeed conveyor (1): 850 x 425mm
  • Discharge conveyor  for cut meat slices (1): 850 x 425mm
  • Overall dimension W x H x D: 910 x 1190 x 1210mm
  • Weight: 240kg
  • Motor performance: 0.75 kW
  • Electrical connection: 3 AC – 400 V – 50 Hz, IEC 60309 16 A 6h, other voltages upon request
  • Compressed air: not required

Additional Information

Brand

Application

Height

1190mm

Width

910mm

Depth

1210mm
