Nock Skinex QS 98 Fish Skinning Machine

Introducing the Nock Skinex QS 98 fish skinning machine, a cutting-edge automatic solution designed for high-capacity fish processing. With its advanced S technology, this conveyorised double-lane fish skinner is equipped with a transport roller featuring fine toothing and a dynamic cleaning roller made of stainless steel, ensuring efficient and effective operation.

For optimal performance, the machine includes an economical water cleaning unit, which supports continuous operation, essential when skinning fish with thin skin. The QS 98 excels at delivering superior yields through three distinct skinning methods: thin skinning with a sharp blade, pulling off the skin with a blunt blade (silver skinning), and deep skinning (with some limitations).



SKU: NOCK-QS98-SKINNER Categories: , ,

Description

The Nock Skinex QS 98 is specifically designed for processing soft fish products like white fish and redfish, making it an ideal replacement for older models such as the BAADER 51, offering more versatile skinning options. Features like an infinitely adjustable blade gap, spring-suspended blade holders, and special polyamide pressure rollers enhance performance while ensuring gentle handling and durability. The machine’s user-friendly design includes easily removable infeed and discharge conveyors, robust NOCK POWER PLATES® construction for easy cleaning and maintenance, and NOCK EASY-FLOW® safety covers for enhanced hygiene during processing. With lockable castors and a trapeze-shaped casing for stability, the QS 98 is not just efficient but also safe and reliable for any fish processing operation.

  • Cutting width: 2 x 200mm
  • Speed of infeed conveyor: 19 m/min
  • Max. throughput height: 40mm
  • Blade gap: 0 – 2mm, infinitely adjustable
  • Apply length on infeed conveyor: 540mm
  • Infeed conveyor (1): 850 x 425mm
  • Discharge conveyor (1): 850 x 425mm
  • Overall dimension W x H x D: 810 x 1190 x 1820mm
  • Weight: 250kg
  • Motor performance: 1.1 kW
  • Electrical connection: 3 AC – 400 V – 50 Hz, IEC 60309 16 A 6h, other voltages upon request
  • Water connection: G 1/4 internal thread
  • Water consumption: approx. 200 l/h
  • Compressed air: not required

Additional Information

Brand

Application

Height

1190mm

Width

810mm

Depth

1820mm
